Z belts

名称	ZRH-UZ
类型	R(roll)、B(belt)
材质	PL65/Cotton35, Xwt
胶粘剂	R/R
砂砾数	24-36-40-60-80-100-120
特色	Zirconia type product with a top-coated activator. ZRHUZ is effective for the difficult grinding material, especially, stainless steels.
应用	ZRH-UZ is effective for difficult grinding materials such as a stainless steel, aluminum and titanium alloy.

名称	ZRH-U	类型	B(belt), WB(wide belt)
材质	PL65/Cotton35, Xwt
胶粘剂	R/R	砂砾数	80
特色	Zirconia type product. It's specialized for grinding the stainless steels and high nickel materials. Especially, a wide belt (<1650mm width) of ZRHU is often used for removing scratches on coiled metal sheet at the coil-grinding line for as wet-grinding(in oil). We can make a max width of 1650mm, length of over 3m abrasive belt.
应用	Coil grinding the stainless steels and high nickel materials by wide belt.

名称	ZRH-E	类型	B(belt), WB(wide belt)
材质	PL65/Cotton35, Xwt
胶粘剂	R/R	砂砾数	60-80
特色	Zr abrasieve dramatically enhance the product life on hevy grinding stainless steels. Wide belt with with of 1650mm are often used for coil grinding the 5 feet stainless steel coils. We can make a max width of 1650mm, length of over 3m abrasive belt.
应用	Stainless steel coil

名称	ZRY-91	类型	B(belt)
材质	PL65/Cotton35 Ywt
胶粘剂	R/R (resin)	砂砾数	24-36-40-60-80-100-120
特色	ZRY91 is developed for heavy grinding by using zirconia abrasive grain and the strongest backing substrate. It is suitable for removing the weld bead and for making a flap wheel.
应用	ZRH-UZ is effective for difficult grinding materials such as a stainless steel, aluminum and titanium alloy.

A belts

名称	ERH	类型	R (roll), B (belt)
材质	Cotton Xwt
胶粘剂	R (resin)	砂砾数	40-50-60-80-100-120-150-180-220-240-280-320-400-500-600
特色	Standard resin-bonded grinding cloth product using alumina grits; widely used as original roll for flap wheels.
应用	Grinding the common metals, glasses. Grit No. of #500 and 600 is often used for pre-polishing for coating.

名称	ERH-E
类型	R (roll), B (belt), WB (wide belt)
材质	PL65/Cotton35, Xwt
胶粘剂	R (resin)
砂砾数	24-30-36-40-50-60-80-100-120-150-180-220-240-280-320-400
特色	ERHE is widely used for grinding and polishing metals such as a carbon steel, stainless steel and nonferrous metals by belt grinding. Wide belt of ERHE is often used in coil grinding for stainless steels. We can make a max width of 1650mm, length of over 3m abrasive belt.
应用	Widely used for grinding and polishing metals and glass such as carbon steels, stainless steels, aluminum alloy, other non-ferous metals.

名称	ERH-T
类型	B (belt)
材质	PL65/Cotton35, Xwt
胶粘剂	R (resin)
砂砾数	40-60-80-100-120-150-180-240-320
特色	An activator is top coated. ERHT is suitable for difficult grinding materials such as stainless steel. In the polishing of SUS304 (X5CrNi18-10) sink, a longer polishing life of 130-250% is achieved more than general abrasive belts.
应用	Dry-grinding and -polishing for stainless steels

名称	ERSE	类型	WB（wide belt)
材质	PL65/Cotton35, Xwt
胶粘剂	R (resin)	砂砾数	60-80-100
特色	ERSE is used for removing scratches on a stainless steel sheet at the coil-grinding line for as wet-grinding(in oil). The grinding surface is mild. We can make a max width of 1650mm, length of over 3m abrasive belt.
应用	Coil grinding for stainless steels

名称	ERSE-B	类型	WB（wide belt)
材质	PL65/Cotton35, Xwt
胶粘剂	R (resin)	砂砾数	80
特色	The backing substrate of ERSEB is stronger than that of ERSE. We can make a max width of 1650mm, length of over 3m abrasive belt.
应用	Coil grinding for stainless steels

名称	EWS	类型	B (belt)
材质	PL65Cotton35, Xwt
胶粘剂	WP(Water proof)	砂砾数	40-60-100-120-150
特色	Particularly for heavy grinding on wet-grinding condition for metals. It also used for carrier belt.
应用	Wet-grinding for carbon steel, stainless steel, cast iron, Ti and Cu alloys.

名称	EWSW	类型	B (belt)
材质	PL65Cotton35, Xwt
胶粘剂	WP(Water proof)	砂砾数	100-120-150-180-220-240--320-400-500-600-800-1000
特色	Long life type for wet grinding and polishing extra water proof. For grinding PC boards and press plates.
应用	Wet-grinding for carbon steel, stainless steel, cast iron, Ti and Cu alloys.

名称	ERJ
类型	R (roll)、B (belt)
材质	Cotton, Xwt
胶粘剂	R (resin)
砂砾数	40-60-80-100-120-150-180-240-320-400
特色	Flexible grinding cloth using white alumina grit. ERJ is suitable for wood sanding and metal light grinding.
应用	Wood sanding, light grinding for metal

C belts

名称	CRS
类型	R (roll)、B (belt)
材质	Cloth, Xwt
胶粘剂	R (resin)
砂砾数	60-80-100-120-150-180-240-320-400-600
特色	CRS consists of silicon carbide abrasives media. It is suitable for grinding and polishing the glass, non-ferrous metals, and finishing such as hair line and satin finish.
应用	Dry- and wet-grinding for a cast iron, non-ferrous metals, glass, ceramics.

名称	CRSE
类型	B (belt), WB(wide belt)
材质	PL65Cotton35, Xwt
胶粘剂	R (resin)
砂砾数	30-40-60-80-100-120-180-400
特色	Wide range of multi-purpose applications as resin belts; Ordinary glasses,metals,alloys,non-ferrous metals and wood working. We can supply CRSE as the wide belt.
应用	Dry- and wet-grinding for a cast iron, stainless steel, non-ferrous metals, glass, ceramics. Finishing for stainless steel.

名称	CRS-F
类型	B (belt)
材质	Cloth, Jwt
胶粘剂	R (resin)
砂砾数	100
特色	CRSF is flexible type products using silicon carbide abrasive medias. Coarse grinding the non-ferrous, curved metals.
应用	Copper alloys, curved metals such as a faucet, tap parts.

名称	Cork CRS
类型	B (belt)
材质	Cloth, Xwt
胶粘剂	R (resin)
砂砾数	60-80-100-240-320-400-500-600-700-800-1000
特色	Cork grit, which coated by fine abrasive medias, is bonded to the substrate. As cork generate the buffer action, these kinds of products shows long life. The grinding surface shows the metalic luster.
应用	Pre-grinding for metalic coating. Removing the light scale on the stainless steel, and burr of plastics, resins and composites.

名称	Cork CRS(E)
类型	B (belt)
材质	Cloth, Xwt
胶粘剂	R (resin)
砂砾数	80-120
特色	Coated cork grits are used. Removing the scales on Ti alloys and carbon steel.
应用	Removing the scales on Ti alloys and carbon steel.

名称	Cork soft
类型	B (belt)
材质	Cloth, Xwt
胶粘剂	R (resin)
砂砾数	240-400-600-800-1000
特色	Extra fine finishing belt.
应用	Extra fine finishing for metals.

Others belts

名称	Felt belt	类型	B (belt)
材质	Cloth, Xwt
胶粘剂	R (resin)	砂砾数	-
特色	Felts are bonded to strong substrate. For finish polishing for showing the metalic luster. This product do not include abrasive media. Use this belt with additional abrasive grits like a buff polishing.
应用	Finishing and buffing.
